EVAPORATOR with Mechanical Vapour Recompressor (MVR)

Asking Price

₹20,00,000

Price is negotiable

Description

EVAPORATOR with Mechanical vapour Recompressor (MVR) Details: Design Specifications Installation : Vertical Shape : Cylindrical Shape Heating Surface : 120 m2 for 1000 LPH Capacity : Type : Plate Type Quantity : 1 No. Material of Construction Shell : SS304 Top & Bottom Cover : SS304 Plate Pack (Heating Surface) : SS316 Distributor : SS304 Demister Pad : SS304 1000LPH VACUUM EVAPORATOR, PARALLEl PLATE FALLING FILM TYPE, WITH SINGLE STAGE MECHANICAL VAPOUR COMPRESSION SYSTEM, FEED TANK, CONDENSATE TANK, PUMPS AND ACCESSORIES, PLC CONTROLLED, ELECTRICAL PANEL INPUT FEED RATE -1000 LPH, 10 BRIX, 65 deg C EVAPORATION- 650 LPH OUTPUT- 350 LPH ,30 BRIX, 70 deg C Total Load -25 kw Accessories: - One (1) Plate type Heat Exchanger - One (1) Plate type Evaporator with MVR system - One (1) Vacuum Pump with Motors - One (1) Recirculation Pump with Motors - One (1) Condensate Tank - One (1) Condensate Pump with Motors - One (1) Concentrated liquor Receiving Tank - One (1) Concentrated liquor Pump with Motors - Flanges / Gaskets / Lifting Lugs / Internal Piping - All the valves fittings for equipment - All pipe line for equipment - Automation with PLC Panel with VFD
